Hobart Ecomax G504SW Glasswasher with Drain Pump and Water Softener

£2640.00 (£3168.00 inc. VAT)

Compact Glasswasher with Drain Pump & Water Softener.

Washes 60 racks of glasses every hour. 500 x 500mm baskets. Loading height of 360mm.

In this range:

G504W – Standard Model with Drain Pump

G504SW – Standard Model with Drain Pump and Water Softener

Spec sheet download

Spec sheet download

Add to Wishlist
Add to Wishlist
Compare

Description

Hobart Ecomax G504SW Glasswasher with Drain Pump and Water Softener

Hobart Ecomax G504SW Glasswasher with Drain Pump and Water Softener is a highly efficient and effective unit that incorporates low running costs and consistent results. The G504SW comes with programme wash cycle times of 60 & 150 seconds, a 500 x 500 basket, electric soft touch controls and rotating top and bottom wash arms with anti-block jets, this unit is essential to deliver a high quality drink experience to your customers.

FEATURES

  • Class “A” air gap
  • Rinse booster pump
  • Integral water softener as standard on the S model
  • Loading height 360mm
  • Racks Per Hour 60
  • Electronic control with digital temperature indication
  • Flat surface of control panel
  • 2 selectable wash cycles
  • Rotating top and bottom wash system to distribute the wash water evenly over the dishes
  • Indented nozzles prevent blocking
  • Thermostop-function for guaranteed temperatures
  • Integrated self-cleaning cycle
  • Removal of rinse arms without any tools
  • USB connection for easier service access
  • Easy access to all parts
  • Deep drawn rack track
  • Door safety lock
  • Double-walled insulated front door
  • Integrated cycle counting, e.g. for control of water treatment system

TECHNICAL SPECIFICATION:

This machine comes as single phase as standard although it is also available as a 3 phase model.  If you require the phase changing, there would be an additional charge and increased lead time.

  • 4.1kW/25A 230/50/1 switchable to 2.2kW/13A
  • 230/50/1 Or 5.9kW/3 x 16A 400/50/3
  • Requires Hardwiring

EXTERNAL DIMENSIONS:

W x D x H 576 x 604 x 820mm


STANDARD EQUIPMENT

  • Glass rack with 5  sloped rows 378814
  • Heater with thermostat control
  • Electric cable, flexible water supply hose and drain hose
  • Rear panelling
  • incl. rinse aid and detergent dispenser and drain pump







Additional information

Weight 64 kg
Dimensions Depth 604 mm , Width 576 mm , Height 820 mm.
Model

G504SW

Brand

Hobart Ecomax

Cycle Duration

60/180 sec

Basket Dimensions

500mm x 500mm

Built in Drain Pump

Yes

Integral Water Softener

Yes

Loading Height

360mm

Warranty

1 years parts and labour warranty

Delivery Options

Free standard delivery, allow 2-3 working days. Excludes highlands and Islands., Whilst we always try to ensure our stock levels are accurate we would always advise you check that the item is in stock if your order is urgent.

Power

Single Phase Electric

Break-tank

No

Chemical Pump

No
