Lincat OE8016 Opus Electric 6 Plate Oven Range

£3944.00 (£4732.80 inc. VAT)

The Opus 800 Electric range 6 plate is designed to deliver fast responsive heat.

Powerful heavy-duty cast iron round hot plates. Large 4 x GN1/1 capacity oven.

Ideal for any busy commercial kitchen.



Add to Wishlist
Add to Wishlist


Lincat OE8016 Opus Electric 6 Plate Oven Range, Round Hotplates

The Lincat Opus Electric 6 Plate Oven Range OE8016 is part of the Opus 800 range. This range offers a wide choice of gas and electric appliances including oven ranges, boiling tops, induction hobs, griddles, grills, chargrills, fryers and steamers. The Lincat oven is essential to any commercial professional catering kitchen.

The Lincat OE8016 is strong and durable, with fully welded stainless steel construction, Opus 800 equipment is built using the highest quality components, ensuring powerful performance and exceptional reliability.

Oven ranges with combined boiling tops are the general purpose workhorse in almost every commercial kitchen. Even outside of food service hours, ovens will be baking, stewing or reducing. Constantly used products like this need to be build to pass the most vigorous of tests.

Lincat Opus ovens are British designed and built in 430 grade steel on the burner top, with double insulated 180˚ opening doors, side and back panels for extra heat-retention efficiency and safety. The ovens themselves have excellent capacity and are lined with long lasting vitreous enamelled steel.


  • 6 x round hotplates
  • Twin zone full width heavy duty hot plate maximises cooking space
  • Two 2.7kW and two 2kW elements produce consistent heat gradient throughout the cast iron plate
  • Outer edge spillage channel to help contain spills within the plate area
  • Twin fan assisted oven for even heat and consistent cooking results
  • Number of Shelves included: 2
    Number of Shelf Positions: 5
  • Gastronorm Capacity: 4 x GN1/1


Total Power kW: 21.6
Temperature Range °C : 130-250
IP Rating: IP24
Cooking Area (Width x Depth) mm: 6 x 214 dia.
Temperature Control: Mechanical
Rating per Hob kW: 2.6
Oven Rating kW : 6.0

Requires Installation: Yes
Requires Electrical Supply: Yes
UK 3 Pin Plug: No
Requires Hardwiring: Yes
Electrical Supply Rating Watts: 21,600
Three Phase Amps L1=31.3; L2=31.3; L3=31.3
Three Phase Voltage: 400


Unit Height (External) mm 925
Unit Width (External) mm 900
Unit Depth (External) mm 800
Shelf Dimensions Width mm 710
Shelf Dimensions Depth mm 512
Hob Dimensions mm 235
Net Weight Kg 129.4


OA8982 – Splashback/Shelf

LK06 – Feet Kit

Electrical appliances MUST be installed by a qualified electrician. Incorrect compliance to current installation legislation will lead to invalidation of warranty.


Additional information

Weight 168 kg
Dimensions Depth 800 mm , Width 900 mm , Height 925 mm.

13 amp standard plug, 3 Phase Electric



Power Requirement

3 phase electric. This unit requires a 3 phase electrical supply to be installed be a qualified electrician.


2 years parts and labour

Delivery Options

Free Standard Delivery, allow up to 4 working days (excludes Scottish Highlands and Islands). Next Day Delivery is available, charges will apply., Whilst we always try to ensure our stock levels are accurate we would always advise you check that the item is in stock if your order is urgent.




Standard (Free)
